Type	A	B(Min)	Φ 1	Φ 2
JB04, JB08,2CL71	5	24	2	0.5
2CL69A, 2CL71A	6.5	24	2.5	0.5
2CL69	8	24	3	0.6
2CL73, 2CL74	10	24	3	0.6

Precausions for Designing
1.The diodes must be used within the specified limits of work and environmental conditions (maximum absolute  ratings), otherwise it will possibly cause damage to the devices. In review of reliability for design, it is necessary for the equipment manufacturer and the circuit designers to make appropriate derating designs for the devices.
2. As the pursuit of miniaturization is concern for the designers of high voltage diode, it is necessary in the application of epoxy resin and other materials for secondary packaging to ensure insulation.
2-1. It is recommended to use epoxy resin for secondary packaging, and the operator should pay attention to the expansion of packaging materials and shrinkage stress, the package should avoid air bubble to ensure that the insulator performance.
2-2.The surface of the high voltage diodes should be kept clean so that good interface for second packaging is well bonded.

Storage Note
1. High voltage diodes should be stored in the environment with temperature range of from 5 ℃ to 35 ℃ and relative humidity below 70%. To avoid the impact of the surrounding environment, immediate usage is recommended after open the package.
2. Such storage places with corrosive gases and dust should be avoided;
3. In case when high voltage diodes stores is more than 6 months, drying shall be applied in oven with temperature of 120 ℃ ± 5 ℃ for not less than 24 hours in order to avoid the impact of temperature.
